Curtain Wall System COMFORT M3 for higher execution speed
Description
M3 is a thermal insulated system for semi-structural curtain walls with hanging frames (stick type) for faster installation
Advantages
- Seamless Design
- Satisfactory Energy Efficiency
- Increased Comfort level
- Increased of security level
- Enhancement of Natural Light
- Guaranteed performance quality in terms of air- water permeability, wind pressure as well as the Uf.
- Increased static and functionality in extreme natural phenomena
- Vast alternatives in custom solutions tailor made to the building
- Ease of use with electric motion
Generic
AESTHETICS
Semi – Stuctural
THERMAL INSULATION
Yes
EXTERIOR SHAPE
Flat
SURFACE TREATMENTS
Wood sublimation , Anodizing colors, all powder coating
Technical Characteristics
EXTERIOR VISIBLE WIDTH
55 mm
TYPE OF THERMAL INSULATION
30mm fiber glass polyamides, PE insulation Foam
MECHANISM
Euro-nut
TYPE OF THERMAL INSULATION
Polyamides12mm width
Performance
SECURITY OF VISIBLE LOAD
Design Load ± 2 KN/m1
WATER TIGHTNESS
R6
AIR PERMEABILITY
Class 4
WIND LOAD RESISTANCE
C4
Characteristics
TRANSOM DEPTH
47 – 154 mm
MULLION MAX INERTIA
501
TYPES OF TYPOLOGY
Fixed, Projected
MULLION DEPTH
49 – 139 mm
TRANSOMS MAX INERTIA
68
UF
from 3,7 W/m²K
TYPE OF HOLDING GLAZING
Seamless Aluminium Frame
MAXIMUM WEIGHT
180 Kg
TYPOLOGIES
Hinged opening outward door
Hinged opening inward door
Projected outward window
Hinged opening inward door
Projected outward window
Parallel projected outward window
Media Gallery
Sections
