Curtain Wall System SMARTIA M50
Description
SMARTIA M50 is a complete system for curtain walls with high energy efficiency, which offers infinite design
possibilities and meets every requirement of contemporary architecture.
Advantages
- Minimal Design
- High Energy Efficiency
- Increased Comfort level
- Increased of security level
- Increased of sound insulation level
- Maximum functionality
- Enhancement of Natural Light
- Guaranteed performance quality in terms of air- water permeability, wind pressure as well as the Uf.
- Increased static and functionality in extreme natural phenomena
- Flexibility in construction
- Vast alternatives in custom solutions tailor made to the building
- Ease of use with electric motion
Generic
AESTHETICS
Standard
THERMAL INSULATION
Yes
EXTERIOR SHAPE
Flat
SURFACE TREATMENTS
Wood sublimation , Anodizing colors, all powder coating
Technical Characteristics
EXTERIOR VISIBLE WIDTH
50 mm
TYPE OF THERMAL INSULATION
30mm fiber glass polyamides, PE insulation Foam
MECHANISM
Euro-nut
TYPE OF THERMAL INSULATION
Polyamides12mm width
Performance
IMPACT RESISTANCE
I5 /E5
SECURITY OF VISIBLE LOAD
Design Load ±3 KN/m2
WATER TIGHTNESS
R7
AIR PERMEABILITY
AE
WIND LOAD RESISTANCE
Design Load ± 2 KN/m1
SOUND REDUCTION
32, 42,47
BURGLAR RESISTANCE
RC3
FIRE RESISTANCE
E30, EW30
BULLET RESISTANCE
FB6S, FB4
WATER TIGHTNESS
CLASS Ε1200
SOUND REDUCTION
45 dB
BURGLAR RESISTANCE
RC2/RC3
Characteristics
TRANSOMS MAX INERTIA
1300
MULLION DEPTH
12 up to 234 mm
TYPES OF TYPOLOGY
Fixed, Projected, Parallel Projected
MULLION MAX INERTIA
1300
MAXIMUM WEIGHT
180 Kg
UF
from 1,0 up to 1,8 W/m²K
TRANSOM DEPTH
12 up to 234 mm
TYPE OF INSTALLATION
Standard
TYPE OF HOLDING GLAZING
Pressure Plate or Structural Silicon
WATER TIGHTNESS
CLASS Ε1200
SOUND REDUCTION
45 dB
BURGLAR RESISTANCE
RC2/RC3
TYPOLOGIES
Tilt and turn window
Parallel and projected outward window
Hinged opening outward door
Hinged opening inward door
Projected outward window
Parallel projected outward window
