Hinged non insulated system COMFORT M940
Description
COMFORT M940 is an economical and lightweight non-insulated system for tilt & turn casements without compromising performance and is available in a variety of solutions.
Advantages
- Very good value for money
- Economic solutions for small spans
- Wide variety of typologies
Generic
WINDOW TYPE
Hinged
THERMAL INSULATION
No
EXTERIOR SHAPE
Classic, Curved, Flat
SURFACE TREATMENTS
Wood sublimation , Anodizing colors, all powder coating
Technical Characteristics
FRAME DEPTH
37 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
81,7 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
131 mm
GLAZING TYPE
Single – Double
MECHANISM
Euro- groove, Euro- nut
MAXIMUM GLAZING THICKNESS
from 4 mm up to 24 mm
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
Performance
WATER TIGHTNESS
CLASS 8A
AIR PERMEABILITY
CLASS 4
CLASS 4
WATER TIGHTNESS
CLASS Ε1200
CLASS Ε1200
SOUND REDUCTION
45 dB
Characteristics
TYPES OF TYPOLOGY
For all tilt & turn typologies
SASH WEIGHT
up to 130 Kg
TYPOLOGIES
One sash tilt and turn
Τilt and turn with fix light on top
Τilt and turn with fanlight
Double tilt and turn window
Double tilt and turn with light
Double tilt and turn window with fixed light
Double tilt and turn window with shutter
Double horizontal parallel sliding window with fixed lights
Hinged inwards entrance door with kick plate
Hinged outwards entrance door with kick plate
Double tilt and turn window with top hung
Double pocket horizontal sliding window with fly-screen & shutter
Media Gallery
Sections
