Hinged insulated system SMARTIA S61

Description

SMARTIA S61 is a sophisticated, thermally-insulating hinged system that combines modern design with exceptional performance. It enhances any space by blending functionality with contemporary aesthetics, providing a perfect connection between indoor and outdoor environments.

Advantages

  • Designed for residential and commercial applications
  • Three energy-efficient options for enhanced insulation and reduced overall energy costs
  • Significant sound reduction thanks to triple glazing
  • Enhanced aesthetics and accessibility with low threshold
  • High safety with the use of multi point locking mechanisms
  • Increased static loads and functionality
  • Ideal for both new constructions and renovations, as it meets the criteria for household energy upgrades

Generic

WINDOW TYPE
Hinged

THERMAL INSULATION
Yes

EXTERIOR SHAPE
Flat

Technical Characteristics

FRAME DEPTH
61 mm

MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
93 mm



MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
151 mm


GLAZING TYPE
Double – Triple
MAXIMUM GLAZING THICKNESS
from 11 to 52 mm



MECHANISM
Euro-groove, Euro-nut

SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets


MINIMUM THRESHOLD HEIGHT
14 mm
SASH DEPTH
69 mm
TYPE OF THERMAL INSULATION
Polyamides 24 mm, PE insulation Foam
SEALING METHOD
Perimetrical with EPDM gaskets & tri-fin brushes


MINIMUM THRESHOLD HEIGHT
24 mm
Performance
WATER TIGHTNESS
E 1200
AIR PERMEABILITY
CLASS 4
WIND LOAD RESISTANCE
CLASS C5
SOUND REDUCTION
46dB
Characteristics
TYPES OF TYPOLOGY
For all tilt & turn typologies, pivot windows

SASH WEIGHT
up to 180 Kg


TYPOLOGIES

Single tilt & turn casement with fanlight
Single tilt & turn casement with P.W.D. low thresold
Double tilt and turn window
Double tilt and turn window with low thresold
Single tilt & turn with fixed light
Double tilt and turn window with fixed light
Double tilt and turn with fanlight
Double tilt and turn window with shutter
Hinged door inwards/outwards
Double leaf door inwards/outwards opening
Hinged door inwards/outwards with insulation panel & fixed pane
Hinged door inwards/outwards with insulation panel, fixed pane & fanlight
