Hinged insulated system SMARTIA S77

Description

The system SMARTIA S77 is ALUMIL’s proposal for advanced insulating casements, which meet the high standards of all advanced markets and incorporate a modern design. It is the ideal solution for projects that require high performance and maximum security.

Advantages

  • Very high energy savings thanks to high energy efficiency (Passive House certified)
  • High security level
  • Exceptional sound insulation
  • Ease of use and high functionality
  • Modern design
  • Ease of access according to specifications for people with special needs and children
  • Wide variety of typologies and solutions
  • Exceptional quality with certified performances
  • Increased static loads and functionality in case of severe weather conditions
  • Suitable for Passive House constructions in regions that lie in warm/temperate climate zone

Generic

WINDOW TYPE
Hinged

THERMAL INSULATION
Yes

EXTERIOR SHAPE
Flat

Technical Characteristics

FRAME DEPTH
77 mm


MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
93 mm



MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
122 mm


GLAZING TYPE
Double – Triple
MAXIMUM GLAZING THICKNESS
from 24 to 72 mm



MECHANISM
Euro-groove, Euro-nut


SEALING METHOD
Perimetrical at 3 levels with EPDM & foam EPDM gaskets


MINIMUM THRESHOLD HEIGHT
13 mm
TYPE OF THERMAL INSULATION
Polyamides 40 mm width, ALUMIL Energy bar, Insulation foam



MECHANISM
91 mm


SEALING METHOD
Perimetrical with EPDM gaskets & tri-fin brushes


MINIMUM THRESHOLD HEIGHT
24 mm
Performance
UF
from 0,85 to 2,42 W/m²K

WATER TIGHTNESS
CLASS E1350

AIR PERMEABILITY
CLASS 4
WIND LOAD RESISTANCE
C5/B5
SOUND REDUCTION
42 dB

BURGLAR RESISTANCE
RC2/RC3

AIR PERMEABILITY
CLASS 4


WIND LOAD RESISTANCE
C4/B4
Characteristics
TYPES OF TYPOLOGY
For all tilt & turn typologies, pivot windows

SASH WEIGHT
up to 180 Kg


TYPOLOGIES

One sash tilt and turn
Single tilt & turn casement with P.W.D. low thresold
Double tilt and turn window
Double tilt and turn window with low thresold
Double tilt and turn with light
Double tilt and turn window with fixed light
Double tilt and turn with fanlight

Horizontal pivot window

Vertical pivot window
Single lifting sliding sash with fixed light
Two lifting sliding sashes with fixed light
Single lifting sliding sash with two fixed lights
